Brand: Widia / Part #: 5697959

Brand: Widia / Part #: 5697959


Item #: 97574271
Brand: Widia
Model #: 5697959

Product Specifications

Cutting Direction Neutral
Hand of Holder Neutral
Compatible Insert Size Code 1204..
Toolholder Style DSDNN
Rake Negative
Rake Angle 0 (Axial);0 (Radial)
Multi-use Tool Yes
Lead Angle 45.000
Insert Holding Method Clamp
Insert Compatibility SN..1204..
Shank Width (mm) 25.00
Shank Height (mm) 32.00
Series DSDN
Overall Length (mm) 170.0000
Cutting Tool Application Facing; Copying; Turning
Head Length (mm) 36.07
Back of Bar to Cutting Edge (mm) 12.00
Primary Workpiece Material Universal
Insert Width (mm) 12.70
Toolholder Material Steel
ISO Number DSDNN3225P12KC04
Complete Insert Compatibility SN..
Insert Thickness 4.76
Coolant Through No
Insert Inscribed Circle (mm) 12.70
$97.12
