Brand: Widia / Part #: 3655895

Brand: Widia / Part #: 3655895


Item #: 98036791
Brand: Widia
Model #: 3655895

Product Specifications

Internal or External External
Maximum Depth of Cut (Decimal Inch) 0.7500
Hand of Holder Left Hand
Maximum Groove Width (Decimal Inch) 0.0940
Minimum Groove Width (Decimal Inch) 0.0937
Toolholder Style WMTSL
Tool Material Steel
Insert Holding Method Clamp
Compatible Insert Size Code S094
Insert Compatibility WMTS094I2BP02PT
Shank Height (Inch) 5/8
Shank Height (Decimal Inch) 0.6250
Shank Length (Decimal Inch) 3.5000
Shank Width/Diameter (Decimal Inch) 0.6250
Shank Width/Diameter (Inch) 5/8
Series WMT
Overall Length (Decimal Inch) 5.0000
Cutting Tool Application Grooving; Cut-Off; Turning
Back of Bar to Cutting Edge (Decimal Inch) 0.6250
Head Height (mm) 23.850
Head Length (Decimal Inch) 1.5000
Primary Workpiece Material Universal
Coolant Through No
$125.55
