Brand: Widia / Part #: 3883284

Brand: Widia / Part #: 3883284


Item #: 02779379
Brand: Widia
Model #: 3883284

Product Specifications

Minimum Bore Diameter (mm) 13.000
Maximum Bore Depth (mm) 30.00
Toolholder Style SCLCL
Tool Material Steel
Shank Diameter (mm) 10.0000
Hand of Holder Left Hand
Overall Length (mm) 125.0000
Compatible Insert Size Code CC..060204
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Left Hand
Rake Angle -7.000
Lead Angle 95.000
Series A-SCLC
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 12.00
Center to Cutting Edge (mm) 7.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (mm) 3.18
Number of Inserts Included in Order 0
Manufacturers Catalog Number A10KSCLCL06
Radial Rake 0
Coolant Through Yes
$125.36
