Brand: Widia / Part #: 5077449

Brand: Widia / Part #: 5077449


Item #: 02808558
Brand: Widia
Model #: 5077449

Product Specifications

Minimum Bore Diameter (mm) 13.000
Maximum Bore Depth (mm) 30.00
Toolholder Style SCFPR
Tool Material Steel
Shank Diameter (mm) 10.0000
Hand of Holder Right Hand
Overall Length (mm) 125.0000
Compatible Insert Size Code CP..0602..
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -6.000
Lead Angle 90.000
Series A-SCFP
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 12.00
Center to Cutting Edge (mm) 7.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (mm) 3.18
Number of Inserts Included in Order 0
Manufacturers Catalog Number A10KSCFPR06
Radial Rake 0
Coolant Through Yes
$122.25
