Brand: Widia / Part #: 2951388

Brand: Widia / Part #: 2951388


Item #: 02768711
Brand: Widia
Model #: 2951388

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.7700
Maximum Bore Depth (Decimal Inch) 1.8750
Toolholder Style SCLCR
Tool Material Steel
Shank Diameter (Decimal Inch) 0.6250
Hand of Holder Right Hand
Shank Diameter (Inch) 5/8
Overall Length (Decimal Inch) 10.0000
Overall Length (Inch) 10
Compatible Insert Size Code CC..2151
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -5.000
Lead Angle -5.000
Series A-SCLC
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.7185
Center to Cutting Edge (Decimal Inch) 0.4060
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Number of Inserts Included in Order 0
Manufacturers Catalog Number A10SSCLCR2
Radial Rake 0
Coolant Through Yes
$122.31
