Brand: Widia / Part #: 5696745

Brand: Widia / Part #: 5696745


Item #: 98265796
Brand: Widia
Model #: 5696745

Product Specifications

Cutting Direction Right Hand
Hand of Holder Right Hand
Compatible Insert Size Code 1604..
Toolholder Style DVONR
Rake Negative
Rake Angle 0 (Axial);0 (Radial)
Multi-use Tool Yes
Lead Angle 117.500
Insert Holding Method Clamp
Insert Compatibility VN..1604..
Shank Width (mm) 20.00
Shank Height (mm) 20.00
Series DVON
Overall Length (mm) 125.0000
Cutting Tool Application Facing; Turning
Head Length (mm) 38.00
Back of Bar to Cutting Edge (mm) 27.00
Primary Workpiece Material Universal
Insert Width (mm) 9.53
Toolholder Material Steel
ISO Number DVONR2020K16KC04
Complete Insert Compatibility VN..
Insert Thickness 4.76
Coolant Through No
Insert Inscribed Circle (mm) 9.53
$112.41
