Brand: Widia / Part #: 2031113

Brand: Widia / Part #: 2031113


Item #: 02771079
Brand: Widia
Model #: 2031113

Product Specifications

Minimum Bore Diameter (mm) 12.000
Maximum Bore Depth (mm) 36.00
Toolholder Style SCMCN
Tool Material Steel
Shank Diameter (mm) 12.0000
Hand of Holder Neutral
Overall Length (mm) 60.0000
Compatible Insert Size Code CC..0602..
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Neutral
Rake Angle 0.000
Lead Angle 50.000
Series LR 50? Boring Bar
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 6.00
Center to Cutting Edge (mm) 0.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Number of Inserts Included in Order 0
Manufacturers Catalog Number S12DSCMCN06
Shank Height (Decimal Inch) 0.4331
Radial Rake 0
Coolant Through No
$108.69
