Brand: Widia / Part #: 5696756

Brand: Widia / Part #: 5696756


Item #: 98529118
Brand: Widia
Model #: 5696756

Product Specifications

Cutting Direction Left Hand
Hand of Holder Left Hand
Compatible Insert Size Code 0804..
Toolholder Style DWLNL
Rake Negative
Rake Angle -5 (Axial);-5 (Radial)
Multi-use Tool Yes
Lead Angle 95.000
Insert Holding Method Clamp
Insert Compatibility WN..0804..
Shank Width (mm) 32.00
Shank Height (mm) 32.00
Series DWLN
Overall Length (mm) 170.0000
Cutting Tool Application Facing; Copying; Turning
Head Length (mm) 24.99
Back of Bar to Cutting Edge (mm) 40.00
Primary Workpiece Material Universal
Insert Width (mm) 12.70
Toolholder Material Steel
ISO Number DWLNL3232P08KC04
Complete Insert Compatibility WN..
Insert Thickness 4.76
Coolant Through No
Insert Inscribed Circle (mm) 12.70
