Brand: Widia / Part #: 3883297

Brand: Widia / Part #: 3883297


Item #: 02778272
Brand: Widia
Model #: 3883297

Product Specifications

Minimum Bore Diameter (mm) 13.000
Maximum Bore Depth (mm) 30.00
Toolholder Style SDUCR
Tool Material Steel
Shank Diameter (mm) 10.0000
Hand of Holder Right Hand
Overall Length (mm) 125.0000
Compatible Insert Size Code DC..070204
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -7.000
Lead Angle 93.000
Series A-SDUC
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 12.00
Center to Cutting Edge (mm) 7.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (mm) 3.20
Number of Inserts Included in Order 0
Manufacturers Catalog Number A10KSDUCR07
Radial Rake 0
Coolant Through Yes
$104.36

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
