Brand: Widia / Part #: 2825364

Brand: Widia / Part #: 2825364


Item #: 02773059
Brand: Widia
Model #: 2825364

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.4130
Maximum Bore Depth (Decimal Inch) 1.1250
Toolholder Style W3755
Tool Material Steel
Shank Diameter (Decimal Inch) 0.3750
Hand of Holder Right Hand
Shank Diameter (Inch) 3/8
Overall Length (Decimal Inch) 5.0000
Overall Length (Inch) 5
Compatible Insert Size Code WP..2151
Insert Holding Method Screw
Compatible Insert Shape Trigon
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -3.000
Lead Angle -3.000
Series QSBIW
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.3985
Center to Cutting Edge (Decimal Inch) 0.2110
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.3850
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (Decimal Inch) 0.0930
Number of Inserts Included in Order 0
Manufacturers Catalog Number QSBIW37553R
Radial Rake 0
Coolant Through Yes
$107.90
