Brand: Widia / Part #: 2951350
Item #: 98373731
Brand: Widia
Model #: 2951350
Product Specifications
| Cutting Direction | Left Hand |
| Hand of Holder | Left Hand |
| Compatible Insert Size Code | 21.5. |
| Toolholder Style | SCLCL |
| Rake | Positive |
| Rake Angle | 0 (Axial);0 (Radial) |
| Multi-use Tool | Yes |
| Lead Angle | 95.000 |
| Insert Holding Method | Screw |
| Shank Width (Decimal Inch) | 0.3750 |
| Shank Width (Inch) | 3/8 |
| Insert Compatibility | CC..21.5. |
| Shank Height (Decimal Inch) | 0.3750 |
| Shank Height (Inch) | 3/8 |
| Series | SCLC |
| Overall Length (Decimal Inch) | 2.5000 |
| Overall Length (Inch) | 2-1/2 |
| Cutting Tool Application | Facing; Copying; Turning |
| Head Length (Decimal Inch) | 0.5000 |
| Back of Bar to Cutting Edge (Inch) | 1/2 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.5000 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Width (Inch) | 1/4 |
| Insert Width (Decimal Inch) | 0.2500 |
| Toolholder Material | Steel |
| ISO Number | SCLCL062 |
| Complete Insert Compatibility | CC.. |
| Coolant Through | No |
| Insert Thickness (Decimal Inch) | 0.0940 |
