Brand: Widia / Part #: 3032715

Brand: Widia / Part #: 3032715


Item #: 99504466
Brand: Widia
Model #: 3032715

Product Specifications

Cutting Direction Right Hand
Hand of Holder Right Hand
Compatible Insert Size Code 1204..
Toolholder Style CCLNR
Rake Negative
Rake Angle -6 (Axial);-6 (Radial)
Multi-use Tool Yes
Lead Angle 95.000
Insert Holding Method Clamp
Insert Compatibility CN.N1204..
Shank Width (mm) 25.00
Shank Height (mm) 25.00
Series CCLN
Overall Length (mm) 150.0000
Cutting Tool Application Facing; Copying; Turning
Head Length (mm) 32.00
Back of Bar to Cutting Edge (mm) 32.00
Primary Workpiece Material Universal
Insert Width (mm) 12.70
Toolholder Material Steel
ISO Number CCLNR2525M12MN4
Complete Insert Compatibility CN.N
Insert Thickness 4.76
Coolant Through No
Insert Inscribed Circle (mm) 12.70
$199.42
