Hydraulic Hose Female JIC 37 & 45 ° Dual Flare Swivel Straight Fitting: 0.5" ID, 8 mm, 3/4-16, 5,000 psi
Item #: 44035129
Brand: Parker
Model #: 10656-8-8
Product Specifications
| Fitting Type | Female JIC 37; 45 Deg Dual Flare Swivel Straight Fitting |
| Hose Inside Diameter (mm) | 0.50 |
| Hose Inside Diameter (Decimal Inch) | 0.5000 |
| Pressure Rating | 5000 |
| Hose Size | 8 |
| Material | Steel |
| Thread Size (Inch) | 3/4-16 |
| Shape | Straight |
| Connection Type | Threaded |
| Overall Length (Decimal Inch) | 2.5400 |
| Overall Length (mm) | 2.54 |
| For Use With | 510C, 518C, 540N, 548N, 560, 590, D6R Hose |
| Standards | California PROP 65 |
| Series | 56 |
| Shaft Type | JIC |
| Body Diameter (Inch) | 1 |
| Hose Diameter (Inch) | 1/2 |
| Hex Size (Inch - 0 Decimals) | 13/16 |
| UNSPSC Code | 40141734 |
