CAT50 1-1/4"-3.5" - Face Mill Arbor

Item #: TE122272535
Manufacturer: Techniks
Mfg #: 22725-3.5

Technical Specifications:
*Arbor Thread: 5/8-18UNF *Brand Name: Techniks *Coolant Supply: Coolant-thru Spindle *Flange Diameter: 3.88 *Gage Length: 3.50 *Key Size: .5 *Pilot Diameter: 1-1/4 *Pilot Length: .69 *Shank: CAT50 *Type: Precision CAT Face Mill Arbor

Description:
*Techniks Face Mill Arbors offerr H6 arbor tolerance for less chatter and better tool life *Each arbor is lab certified for dimensional accuracy *The taper is ground to AT3 tolerance for maximum spindle contact

Shipping Info:
*Actual Weight - 10.7000
