7/8″ min - 20 GF Style Coolant Thru Thread Mill
Item #: ER4516650
Brand: EMUGE-FRANKEN
Model #: GF162331.9580
| Product Specifications | |
|---|---|
| Thread Size | 7/8″ |
| Coolant Supply Property (CSP) | Coolant Thru |
| Threads per Inch (TPI) | 20 |
| Shank Type | HB |
| Thread Diameter Size (TDZ) | 7/8″ |
| Coating | Bright |
| Thread Standard | UN |
| Application | | Thread Milling | |
| Connection Diameter Machine Side (DCONMS) | 16 mm |
| Cutting Edge Material | Carbide |
| Overall Length (OAL) | 90 mm |
| Usable Length (LU) | 32.3 mm |
| Flute Count (NOF) | 5 |
| Series/List # | A214524 |
