Brand: Widia / Part #: 2008119
Item #: 90738808
Brand: Widia
Model #: 2008119
Product Specifications
| End Type | Double-Ended |
| Cutting Direction | Neutral |
| Hand | Neutral |
| Blade Height (mm) | 32.00 |
| Blade Width (mm) | 3.20 |
| Blade Overall Length (mm) | 150.00 |
| Blade Style | ProGroove |
| Compatible Insert Style | PG. |
| Compatible Insert Size Code | 4 |
| Tool Material | Steel |
| Insert Holding Method | Self Grip |
| Maximum Workpiece Diameter (mm) | 100.00 |
| Series | ProGroove |
| Insert Style | ProGroove |
| Cutting Tool Application | Cut-Off |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | O |
| Insert Seat Size | 4 |
| Maximum Depth of Cut (mm) | 50.00 |
| Cutting Height (mm) | 25.00 |
| Minimum Insert Width (mm) | 4.00 |
| Maximum Insert Width (mm) | 4.00 |
| Complete Insert Compatibility | PGM; PGR; PGS; PGU |
| Manufacturers Catalog Number | 12251354000 |
| Blade Type | Double-Sided |
