Brand: Widia / Part #: 2748295
Item #: 97628648
Brand: Widia
Model #: 2748295
Product Specifications
| Thread Size (mm) | M5x0.8 |
| Chamfer | Plug |
| Thread Limit | D4 |
| Class Of Fit | 6H |
| Number Of Flutes | 3 |
| Material | High Speed Steel |
| Threads per Inch | 32 |
| Thread Direction | Right Hand |
| Flute Direction | Right Hand |
| Coating/Finish | Uncoated |
| Thread Depth (mm) | 22.35 |
| Coolant Through | No |
| Thread Length (mm) | 12.70 |
| Overall Length (mm) | 60.4500 |
| Thread Pitch (mm) | 0.80 |
| Thread Standard | Metric |
| Shank Diameter (mm) | 4.9300 |
| Material Application | Non-Ferrous Metal |
| Series | 2364/5364 |
