Brand: Widia / Part #: 2832120

Brand: Widia / Part #: 2832120


Item #: 90335027
Brand: Widia
Model #: 2832120

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.2340
Maximum Bore Depth (Decimal Inch) 2.0000
Maximum Bore Depth (Inch) 2
Toolholder Style CCBI
Tool Material Carbide
Shank Diameter (Decimal Inch) 0.5000
Hand of Holder Right Hand
Shank Diameter (Inch) 1/2
Overall Length (Decimal Inch) 3.5000
Overall Length (Inch) 3-1/2
Compatible Insert Size Code CD..120605
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle -5.000
Series CCBI STEPPED
Insert Inscribed Circle (Inch) 5/32
Insert Inscribed Circle (Decimal Inch) 0.1563
Insert Inscribed Circle (mm) 3.97
Compatible Insert Thickness (Decimal Inch) 0.0400
Compatible Insert Thickness (mm) 1.02
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.3690
Center to Cutting Edge (Decimal Inch) 0.1190
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0400
Coolant Hole Diameter (Decimal Inch) 0.1250
Number of Inserts Included in Order 0
Manufacturers Catalog Number CCBI20350025R
Radial Rake 5
Coolant Through Yes
$371.50
