Straight Flute Tap: M16x1.5 M, 3 Flute, Bottoming Chamfer, 6HX Class of Fit, Powdered Metal HSS, ta-C (DLC) Finish
Item #: 02218436
Brand: Sandvik Coromant
Model #: 8330331
Product Specifications
| Tap Type | Straight Flute |
| Thread Size (mm) | M16x1.5 |
| Thread Standard | M |
| Chamfer | Bottoming |
| Material | Powdered Metal High-Speed Steel |
| Coating/Finish | ta-C (DLC) |
| Thread Direction | Right Hand |
| Coolant Through | Yes |
| Class Of Fit | 6HX |
| Number Of Flutes | 3 |
| Overall Length (Decimal Inch) | 3.7402 |
| Overall Length (mm) | 95 |
| Thread Length (Decimal Inch) | 0.8268 |
| Thread Length (mm) | 21.00 |
| Application | Blind Hole Threading; Through-Hole Threading |
| Shank Diameter (mm) | 12.5000 |
| Shank Diameter (Decimal Inch) | 0.4921 |
| Tapping Depth (mm) | 50.00 |
| Tapping Depth (Decimal Inch) | 1.9685 |
| Material Application | Non-Ferrous Metal |
| Series | CoroTap™ 100 |
| UNSPSC Code | 23291800 |
