Brand: Widia / Part #: 3029011
Item #: 02918175
Brand: Widia
Model #: 3029011
Product Specifications
| Minimum Bore Diameter (mm) | 40.000 |
| Maximum Bore Depth (mm) | 120.00 |
| Toolholder Style | CCLNR |
| Tool Material | Steel |
| Insert Compatibility | CN.N1204.. |
| Shank Diameter (Decimal Inch) | 1.5748 |
| Shank Diameter (mm) | 40.0000 |
| Hand of Holder | Right Hand |
| Overall Length (mm) | 300.0000 |
| Compatible Insert Size Code | 1204.. |
| Insert Holding Method | Clamp |
| Insert Included | No |
| Rake | Negative |
| Cutting Direction | Right Hand |
| Rake Angle | 0.000 |
| Lead Angle | 95.000 |
| Series | S40T |
| Insert Inscribed Circle (mm) | 12.70 |
| Multi-use Tool | Yes |
| Cutting Tool Application | Boring |
| Back of Bar to Cutting Edge (mm) | 47.00 |
| Primary Workpiece Material | Universal |
| Multi-Use Application | Boring |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Head Length (Decimal Inch) | 1.5748 |
| Coolant Through | No |
