Brand: Ingersoll Cutting Tools / Part #: 5840786
Item #: 60489374
Brand: Ingersoll Cutting Tools
Model #: 5840786
Product Specifications
| Insert Style | TNGU |
| Insert Size Code | 2207 |
| Insert Material | Carbide |
| Manufacturer Grade | IN2505 |
| Inscribed Circle (Inch) | 1/2 |
| Corner Radius (Inch) | 3/32 |
| Insert Hand | Neutral |
| Series | TNGU |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.3200 |
| Number Of Cutting Edges | 3 |
| Insert Shape | Triangle |
| Rake | Negative |
| Primary Workpiece Material | Hard Material; Cast Iron; Steel |
| Primary Workpiece Material Code | P; H; K |
| Ansi Code | TNGU2207PNTN |
| Rake Angle | 0.000 |
| Manufacturers Catalog Number | TNGU2207PNTN IN2505 |
| Chip Breaker | None |
| Cutting Direction | Neutral |
| Shape | Triangle |
| Insert Holding Method | Screw |
| Thickness (mm) | 8.0000 |
| Coating Classification | PVD |
| Single or Double Sided Insert | Double |
| Coating/Finish | TiN; TiAlN |
| Included Angle Degree | 60 |
| Multi-Use Tool | Yes |
