Brand: Widia / Part #: 2825297

Brand: Widia / Part #: 2825297


Item #: 28787893
Brand: Widia
Model #: 2825297

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.4380
Maximum Bore Depth (Decimal Inch) 2.6250
Toolholder Style QCBI
Tool Material Carbide
Shank Diameter (Decimal Inch) 0.3750
Hand of Holder Left Hand
Shank Diameter (Inch) 3/8
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Compatible Insert Size Code TP..21505
Insert Holding Method Screw
Compatible Insert Shape Triangle
Insert Included No
Rake Positive
Cutting Direction Left Hand
Rake Angle 0.000
Lead Angle -5.000
Series QCBI
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.4155
Center to Cutting Edge (Decimal Inch) 0.2280
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (Decimal Inch) 0.1250
Number of Inserts Included in Order 0
Manufacturers Catalog Number QCBI37565L
Radial Rake 5
Coolant Through Yes
$323.53
