Knee Powerfeed Type 200 for Acer; 3VS; 3VK

Item #: JD80M9810200
Manufacturer: Servo
Mfg #: M-9810-200

Technical Specifications:
•Brand Name: Servo •Description: Z-Axis Knee Feed •For Use With: Acer 3VS & 3VK •Model Number: M-9810-200 •Type: 200

Description:
•Semi-automated machining on Class 1 mills to 5 hp. •Peak Torque (half-wave series motor): to 200 in.- lb. / 22.6 NM torque •Intermittent Torque: 150 in.- lb. / 17 NM •Continuous Torque: 120 in.- lb. / 13 NM •Variable Feed Rate: .5-12 IPM / 13-305 mm/min (knee) •Rapid Traverse: 15IPM / 381 mm/min. (knee) •Gear Reduction Ratio (motor to screw shaft): 72:1. •Helical gearing and torque limiting friction safety clutch with new and improved gear •Electrical: 110V, 50/60 Hz, 4.0A. •Approx. weight: 21 lb. / 9.4 kg.

Shipping Info:
•Actual Weight - 21.0000
