Brand: Widia / Part #: 3655928

Brand: Widia / Part #: 3655928


Item #: 98384522
Brand: Widia
Model #: 3655928

Product Specifications

Internal or External External
Maximum Depth of Cut (Decimal Inch) 1.0000
Hand of Holder Right Hand
Maximum Groove Width (Decimal Inch) 0.2500
Minimum Groove Width (Decimal Inch) 0.3150
Toolholder Style WMTSR
Tool Material Steel
Insert Holding Method Clamp
Compatible Insert Size Code S250
Insert Compatibility WMTS250I6P03PT
Shank Height (Inch) 1
Shank Height (Decimal Inch) 1.0000
Shank Length (Decimal Inch) 4.1740
Shank Width/Diameter (Decimal Inch) 1.0000
Shank Width/Diameter (Inch) 1
Series WMT
Overall Length (Decimal Inch) 6.0000
Cutting Tool Application Grooving; Cut-Off; Turning
Back of Bar to Cutting Edge (Decimal Inch) 1.0020
Head Height (mm) 34.930
Head Length (Decimal Inch) 1.8260
Primary Workpiece Material Universal
Insert Seat Size 6.0
Coolant Through No
$125.55
