Brand: Widia / Part #: 2823032

Brand: Widia / Part #: 2823032


Item #: 02769354
Brand: Widia
Model #: 2823032

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.6680
Maximum Bore Depth (Decimal Inch) 1.5000
Toolholder Style SSBI
Tool Material Steel
Shank Diameter (Decimal Inch) 0.5000
Hand of Holder Left Hand
Shank Diameter (Inch) 1/2
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Compatible Insert Size Code TP..3205
Insert Holding Method Screw
Compatible Insert Shape Triangle
Insert Included No
Rake Positive
Cutting Direction Left Hand
Rake Angle 0.000
Lead Angle -5.000
Series SSBI
Insert Inscribed Circle (Inch) 3/8
Compatible Insert Thickness (Decimal Inch) 0.1250
Compatible Insert Thickness (mm) 3.18
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.5890
Center to Cutting Edge (Decimal Inch) 0.3390
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.5720
Insert Thickness (Decimal Inch) 0.1250
Insert Thickness (Inch) 1/8
Coolant Hole Diameter (Decimal Inch) 0.1560
Number of Inserts Included in Order 0
Manufacturers Catalog Number SSBI50065L
Radial Rake 5
Coolant Through Yes
$118.14
