Brand: Sandvik Coromant / Part #: 8351135
Item #: 67619957
Brand: Sandvik Coromant
Model #: 8351135
Product Specifications
| System Size | 20 |
| Minimum Hole Diameter (Decimal Inch) | 1.0630 |
| Minimum Hole Diameter (mm) | 27.00 |
| Cutting Direction | Left Hand |
| Compatible Insert Style | DCMT |
| Compatible Insert Size Code | 11T3 |
| Internal or External | Internal |
| Insert Holding Method | Screw |
| Center to Cutting Edge (mm) | 16.50 |
| Center to Cutting Edge (Decimal Inch) | 0.6500 |
| Series | CoroTurn? 107 |
| Neck Diameter (mm) | 20.000 |
| Neck Diameter (Decimal Inch) | 0.7874 |
| Cutting Tool Application | Turning |
| Complete Insert Compatibility | DCMT 11T304 |
| Coolant Through | Yes |
| Head Length Projection (Decimal Inch) | 0.7874 |
| Head Length Projection (mm) | 20.00 |
