Brand: Widia / Part #: 2058066
Item #: 99765398
Brand: Widia
Model #: 2058066
Product Specifications
| Internal or External | External |
| Toolholder Type | External Grooving |
| Insert Seat Size | 22 |
| Hand of Holder | Neutral |
| Cutting Direction | Neutral |
| Maximum Depth of Cut (mm) | 1.00 |
| Minimum Groove Width (mm) | 22.00 |
| Maximum Groove Width (mm) | 22.00 |
| Toolholder Style | 121910 |
| Insert Holding Method | Clamp |
| Insert Compatibility | TP..2204../TP..43.. |
| Compatible Insert Size Code | TP..2204../TP..43. |
| Shank Width/Diameter (mm) | 18.00 |
| Shank Height (mm) | 0.00 |
| Series | 121910 |
| Shank Length (mm) | 115.000 |
| Overall Length (mm) | 150.0000 |
| Multi-use Tool | No |
| Cutting Tool Application | Grooving |
| Head Length (mm) | 35.00 |
| Mount Type | Shank |
| Manufacturers Catalog Number | 12191062686 |
| Toolholder Material | Steel |
| Insert Hand | Neutral |
| Coolant Through | No |
| Minimum Bore Diameter (mm) | 0.000 |
| Maximum Bore Depth (mm) | 0.00 |
