Brand: Widia / Part #: 3879317

Brand: Widia / Part #: 3879317


Item #: 98434012
Brand: Widia
Model #: 3879317

Product Specifications

Cutting Direction Left Hand
Hand of Holder Left Hand
Compatible Insert Size Code 1506..
Toolholder Style PDJNL
Rake Negative
Rake Angle -7 (Axial);-6 (Radial)
Multi-use Tool Yes
Lead Angle 93.000
Insert Holding Method Pin
Insert Compatibility DN..1506..
Shank Width (mm) 20.00
Shank Height (mm) 20.00
Series PDJN
Overall Length (mm) 125.0000
Cutting Tool Application Copying; Turning
Head Length (mm) 36.07
Back of Bar to Cutting Edge (mm) 25.00
Primary Workpiece Material Universal
Insert Width (mm) 12.70
Toolholder Material Steel
ISO Number PDJNL2020K15
Complete Insert Compatibility DN..
Insert Thickness 6.35
Coolant Through No
Insert Inscribed Circle (mm) 12.70
$103.67
