Brand: Widia / Part #: 4047662
Item #: 40049215
Brand: Widia
Model #: 4047662
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 1.4500 |
| Maximum Cutting Diameter (Decimal Inch) | 2.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.0490 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Compatible Insert Size Code | WOEJ080412SRMH |
| Maximum Ramping Angle | 0.83 |
| Cutter Style | M370 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Series | M370 |
| Maximum Body Diameter (Decimal Inch) | 1.9210 |
| Keyway Width (mm) | 8.14 |
| Overall Height (Decimal Inch) | 1.5750 |
| Maximum RPM | 29000.000 |
| Tool Application | Facing; Helical Interpolation; Plunging; Slotting; Shouldering; Ramping |
| Tool Performance | High Performance |
| Primary Workpiece Material | Universal |
| Number Of Cutter Inserts | 7 |
| Number Of Flutes | 7 |
| Coolant Through | Yes |
