Brand: Widia / Part #: 2825788

Brand: Widia / Part #: 2825788


Item #: 02773653
Brand: Widia
Model #: 2825788

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.5630
Maximum Bore Depth (Decimal Inch) 1.5000
Toolholder Style QSBI
Tool Material Steel
Shank Diameter (Decimal Inch) 0.5000
Hand of Holder Right Hand
Shank Diameter (Inch) 1/2
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Compatible Insert Size Code TP..21505
Insert Holding Method Screw
Compatible Insert Shape Triangle
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle 0.000
Series QSBI
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.5460
Center to Cutting Edge (Decimal Inch) 0.2960
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.5100
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (Decimal Inch) 0.1560
Number of Inserts Included in Order 0
Manufacturers Catalog Number QSBI50060R
Radial Rake 5
Coolant Through Yes
$116.36
