Brand: Widia / Part #: 5564328

Brand: Widia / Part #: 5564328


Item #: 99312530
Brand: Widia
Model #: 5564328

Product Specifications

Cutting Direction Right Hand
Hand of Holder Right Hand
Compatible Insert Size Code 54.
Toolholder Style DCLNR
Rake Negative
Rake Angle -5 (Axial);-5 (Radial)
Multi-use Tool Yes
Lead Angle 95.000
Insert Holding Method Clamp
Shank Width (Decimal Inch) 1.5000
Shank Width (Inch) 1-1/2
Insert Compatibility CN..54.
Shank Height (Decimal Inch) 1.5000
Shank Height (Inch) 1-1/2
Series DCLN
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Cutting Tool Application Facing; Turning
Head Length (Decimal Inch) 1.3800
Back of Bar to Cutting Edge (Inch) 2
Back of Bar to Cutting Edge (Decimal Inch) 2.0000
Primary Workpiece Material Universal
Insert Inscribed Circle (Decimal Inch) 0.6250
Insert Inscribed Circle (Inch) 5/8
Insert Width (Inch) 5/8
Insert Width (Decimal Inch) 0.6250
Toolholder Material Steel
ISO Number DCLNR245DKC4
Complete Insert Compatibility CN..
Coolant Through No
Insert Thickness (Decimal Inch) 0.2500
$116.47
