Brand: Widia / Part #: 2822921

Brand: Widia / Part #: 2822921


Item #: 02809077
Brand: Widia
Model #: 2822921

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.8500
Maximum Bore Depth (Decimal Inch) 2.2500
Toolholder Style SSBI
Tool Material Steel
Shank Diameter (Decimal Inch) 0.7500
Hand of Holder Right Hand
Shank Diameter (Inch) 3/4
Overall Length (Decimal Inch) 4.0000
Overall Length (Inch) 4
Compatible Insert Size Code TP..3205
Insert Holding Method Screw
Compatible Insert Shape Triangle
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle -5.000
Series SSBI
Insert Inscribed Circle (Inch) 3/8
Compatible Insert Thickness (Decimal Inch) 0.1250
Compatible Insert Thickness (mm) 3.18
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.8350
Center to Cutting Edge (Decimal Inch) 0.4600
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.7600
Insert Thickness (Decimal Inch) 0.1250
Insert Thickness (Inch) 1/8
Coolant Hole Diameter (Decimal Inch) 0.1560
Number of Inserts Included in Order 0
Manufacturers Catalog Number SSBI75045R
Radial Rake 5
Coolant Through Yes
$116.36
