Brand: Panduit / Part #: LCD8-14A-L
Item #: 30909105
Brand: Panduit
Model #: LCD8-14A-L
Product Specifications
| Terminal Type | Rectangle |
| Insulation Type | Non-Insulated |
| Connection Type | Compression |
| Compatible Wire Size (AWG) | 8 |
| Color | Red |
| Stud Size (Inch) | 1/4 |
| Contact Material | Copper |
| Contact Plating | TiN |
| Thickness (Decimal Inch - 4 Decimals) | 0.0700 |
| Ring Width (Decimal Inch) | 0.4800 |
| Overall Length (Decimal Inch) | 1.9700 |
