Aloris - 25 and Up Inch Lathe Swing, Wedge Type Quick Change Tool Post - 8-1/2 Inch Tool Post Height, Series EA, 3 to 3-11/16 Inch Centerline Height Range, 10 Inch Overall Height, 24 Position
Item #: 98230212
Brand: Aloris
Model #: EA
Exact Tooling IR#: 04
Features and Benefits
The clamping mechanism is a wedge that pushes out from the side of the dovetail when the clamping lever on the tool post is engaged.
| Product Specifications | |
|---|---|
| Type | Quick Change Tool Post - Wedge Type |
| Series | EA |
| Lathe Swing (Inch) | 25 & Up |
| Through Coolant | No |
| Base Width (Inch) | 6 |
| Tool Post Height (Inch) | 8-1/2 |
| Centerline to Handle Edge (Inch) | 13-13/16 |
| Bolt Hole Diameter (Inch) | 1-1/4 |
| Overall Height (Inch) | 10 |
| Centerline to Body (Inch) | 3-1/8 |
| Minimum Centerline Height (Inch) | 3 |
| Maximum Centerline Height (Inch) | 3-11/16 |
| Body Height (Inch) | 5 |
| Number of Positions | 24 |
| Repeatability (Decimal Inch) | 0.000050 |
| Includes | Mounting Wrench |
