Woodworking Lathes; Swing (Inch): 14; Distance Between Centers (Decimal Inch): 24.0150; Swing Over Tool Rest Base (Inch): 13.0000; Swing Over Tool Rest Base (Decimal Inch): 13.0000; Face Plate Diameter (Inch): 3.0000; Spindle Nose Designation: 1-1/4 - 8;
Item #: 95844486
Brand: Vectrax
Model #: V-T-40
Product Specifications
| Swing (Inch) | 14 |
| Distance Between Centers (Decimal Inch) | 24.0150 |
| Swing Over Tool Rest Base (Inch) | 13.0000 |
| Swing Over Tool Rest Base (Decimal Inch) | 13.0000 |
| Face Plate Diameter (Inch) | 3.0000 |
| Spindle Nose Designation | 1-1/4 - 8 |
| Tool Rest Size (Inch) | 12 |
| Headstock Taper Size | 2MT |
| Tailstock Taper Size | 2MT |
| Number of Indexing Positions | 24 |
| Maximum Spindle Speed (RPM) | 4300 |
| Minimum Spindle Speed (RPM) | 20 |
| Headstock Spindle Hole Size (Inch) | 1/2 |
| Tailstock Quill Travel (Inch) | 4 |
| Bed Construction | Cast Iron |
| Horsepower (HP) | 1 |
| Voltage | 220 |
| Phase | 1 |
| Overall Depth (Decimal Inch) | 17.1260 |
