McGill - 5/8" Roller Diam x 7/16" Width, 1/4" Stud Diam x 3/4" Length, Sealed Self Lubricating Stud Cam Follower with Nonmetallic Bushing and Hex - Steel, 5/16" Thread Length, 1/4-28 Thread, 1.22" OAL
Item #: 92611839
Brand: McGill
Model #: BCF 5/8 SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Self-Lubricating Stud Cam Follower with Non-Metallic Bushing and Hex |
| Roller Diameter (Decimal Inch) | 0.6250 |
| Roller Diameter (Inch) | 5/8 |
| Roller Width (Decimal Inch) | 0.4375 |
| Roller Width (Inch) | 7/16 |
| Stud Diameter (Decimal Inch) | 0.2500 |
| Length (Decimal Inch) | 1.220 |
| Thread Size | 1/4-28 |
| Material | Steel |
| Stud Length (Decimal Inch) | 0.7500 |
| Stud Length (Inch) | 3/4 |
| Thread Length (Inch) | 5/16 |
| McGill Part Number | BCF 5/8 SB |
| Roller Type | Non Metallic Bushing |
