Cooper Lighting - 1 and 2 Face, 2 Head, 120-277 Volt, Thermoplastic, LED Combination Exit Sign - 2-5/16 Inch Wide x 8-1/4 Inch High x 16-9/16 Inch Long, Ceiling, End and Wall Mount, Sealed Nickel Cadmium Battery
Item #: 89201826
Brand: Cooper Lighting
Model #: APC7R
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Type | Ceiling Mount; End Mount; Wall Mount |
| Number of Faces | 1; 2 |
| Lamp Type | LED |
| Number of Heads | 2 |
| Overall Length (mm) | 421 |
| Overall Length (Inch) | 16-9/16 |
| Overall Length (Decimal Inch) | 16-9/16 |
| Battery Type | Sealed Nickel Cadmium |
| Voltage | 120/277 |
| Overall Width (mm) | 59 |
| Overall Width (Inch) | 2-5/16 |
| Overall Width (Decimal Inch) | 2.3100 |
| Housing Color | White |
| Letter Color | Red |
| Overall Height (mm) | 210 |
| Overall Height (Inch) | 8-1/4 |
| Housing Material | Thermoplastic |
| Maximum Operating Temperature (F) | 104 |
| Minimum Operating Temperature (F) | 50 |
| Includes | Snap-Fit Canopy |
| Standards Met | NEC; NFPA 101; OSHA; UL; UL Listed 924 |
| PSC Code | 6210 |
