Gardner Spring - #8 Bolt, 0.164" ID, Grade 1074 Steel, Belleville Disc Spring - 1/2" OD, 0.037" High, 0.025" Thick
Item #: 87778379
Brand: Gardner Spring
Model #: MB0499-025
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Screw Size (Wire) | #8 |
| Inside Diameter (Decimal Inch) | 0.1640 |
| Material | Steel |
| Material Grade | 1074 |
| Outside Diameter (Decimal Inch) | 0.5000 |
| Thickness (Decimal Inch) | 0.0250 |
| Overall Height (Decimal Inch) | 0.0370 |
| Deflection (Decimal Inch) | 0.0060 |
| Load at Flat (Lb.) | 128.17 |
| Load at Deflection (Lb.) | 69.62 |
