Gardner Spring - #6 Bolt, 0.138" ID, Grade 1074 Steel, Belleville Disc Spring - 9/32" OD, 0.021" High, 0.013" Thick
Item #: 87778296
Brand: Gardner Spring
Model #: MB0281-013
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Screw Size (Wire) | #6 |
| System of Measurement | Inch |
| Inside Diameter (Decimal Inch) | 0.1380 |
| Material | Steel |
| Material Grade | 1074 |
| Outside Diameter (Decimal Inch) | 0.2810 |
| Thickness (Decimal Inch) | 0.0130 |
| Overall Height (Decimal Inch) | 0.0210 |
| Deflection (Decimal Inch) | 0.0040 |
| Deflection to Flat (Decimal Inch) | 0.0040 |
| Minimum Inside Diameter (Decimal Inch) | 0.1380 |
| Maximum Outside Diameter (Decimal Inch) | 0.2810 |
| Load at Flat (Lb.) | 42.30 |
| Load at Deflection (Lb.) | 24.20 |
