Square End Mill: 1'' Dia, 2'' LOC, 1'' Shank Dia, 4-1/2'' OAL, 6 Flutes, Powdered Metal Single End, TiCN Finish, Spiral Flute, Centercutting, RH Cut, RH Flute, Series PM-4
Item #: 87434379
Brand: Cleveland
Model #: C32009
Product Specifications
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Mill Diameter (mm) | 25.40 |
| Number Of Flutes | 6 |
| Length of Cut (Inch) | 2 |
| End Mill Material | Powdered Metal Cobalt (HSS-E-PM) |
| End Type | Single |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Shank Diameter (Inch) | 1 |
| Finish/Coating | TiCN |
| Overall Length (Inch) | 4-1/2 |
| Helix Angle | 37 |
| Chipbreaker | No |
| Variable Helix | No |
| Variable Index | No |
| Extended Reach | No |
| Length Of Cut Range (Decimal Inch) | 2.0000+ |
| Shank Type | Weldon Flat; Straight-Cylindrical |
| Length of Cut (Decimal Inch) | 2.0000 |
| Material Grade | M42 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 4.5000 |
| Flute Direction | Right Hand |
| Flute Type | Spiral |
| Helix Style | Medium |
| Length Type | Regular |
| Series | PM-4 |
