CNC Milling Machine: 16-3/4 x 62″ Table, 3 Phase, Fagor Variable Speed Pulley Control, NT40 Taper, 47.24″ Longitudinal Travel, 22.83″ Cross Travel, 7.5 hp
Item #: 87319182
Brand: Clausing
Model #: Sup8BVSCNCFG
Product Specifications
| CNC Controller Brand | Fagor |
| CNC Controller Model | 8055i CNC |
| Spindle Speed Control | Variable Speed Pulley |
| Table Length (Decimal Inch) | 62.0000 |
| Table Length (Inch) | 62 |
| Table Width (Inch) | 16-3/4 |
| Phase | 3 |
| Longitudinal Travel (Decimal Inch) | 47.2400 |
| Cross Travel (Decimal Inch) | 22.8300 |
| Knee Travel (Decimal Inch) | 23.6200 |
| Minimum Spindle Speed | 65 RPM |
| Spindle Travel Length (Decimal Inch) | 6.0000 |
| Spindle Travel Length (Inch) | 6 |
| Spindle Taper Size | NT40 |
| Quill Diameter (Decimal Inch) | 4.3300 |
| Maximum Spindle to Table Distance (Decimal Inch) | 27.5500 |
| Number Of T-slots | 4 |
| Left-Hand Head Tilt (Degrees) | 90.00 |
| Right-Hand Head Tilt (Degrees) | 90 |
| Positioning Accuracy (Decimal Inch) | 0.0004 |
| Positioning Repeatability (Decimal Inch) | 0.0002 |
| Voltage | 220; 440 |
| Horsepower | 7.50 |
| Overall Height (Decimal Inch) | 84.6500 |
| Overall Length (Decimal Inch) | 68.0000 |
| Overall Length (Inch) | 98 |
| Overall Depth (Inch) | 81 |
| Overall Depth (Inch) | 81.0000 |
| Table Load Capacity (Lb.) | 2000.00 |
