Brand: Widia / Part #: 2832353
Item #: 95259321
Brand: Widia
Model #: 2832353
Product Specifications
| Internal or External | Internal |
| Toolholder Type | Internal Grooving |
| Insert Seat Size | 5 |
| Hand of Holder | Right Hand |
| Cutting Direction | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.0400 |
| Minimum Groove Width (Decimal Inch) | 0.0300 |
| Toolholder Style | CSMI |
| Maximum Groove Width (Decimal Inch) | 0.0300 |
| Insert Holding Method | Screw |
| Insert Compatibility | CD.5.. |
| Compatible Insert Size Code | 5 |
| Shank Width/Diameter (Decimal Inch) | 0.1875 |
| Shank Height (Decimal Inch) | 2.0790 |
| Series | CSMI |
| Shank Length (Decimal Inch) | 2.0790 |
| Overall Length (Decimal Inch) | 2.5000 |
| Multi-use Tool | No |
| Cutting Tool Application | Grooving |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.2478 |
| Center to Cutting Edge (Decimal Inch) | 0.1540 |
| Minimum Hole Diameter (Decimal Inch) | 0.2720 |
| Head Length (Decimal Inch) | 0.0000 |
| Primary Workpiece Material | Universal |
| Vibration Dampening | No |
| Coolant Hole Diameter (Decimal Inch) | 0.0400 |
| Maximum Bore Depth (Decimal Inch) | 0.9400 |
| Mount Type | Shank |
| Manufacturers Catalog Number | CSMI187250R |
| Toolholder Material | Steel |
| Insert Hand | Left Hand |
| Complete Insert Compatibility | CD.5.. |
| Minimum Bore Diameter (Decimal Inch) | 0.2720 |
| Coolant Through | Yes |
