120° 70mm OAL High Speed Steel Spotting Drill Bright/Uncoated, 17mm Flute Length, 6.35mm Shank Diam, RH Cut, Series 556
Item #: 85786168
Brand: Guhring
Model #: 9005560063500
Product Specifications
| Drill Point Angle | 120 |
| Cutting Diameter (Inch) | 1/4 |
| Cutting Diameter (Decimal Inch) | 0.2500 |
| Overall Length (mm) | 70.00 |
| Tool Material | High Speed Steel |
| Coating/Finish | Bright/Uncoated |
| Single/Double Ended | Single |
| Series | 556 |
| Overall Length (Decimal Inch) | 2.7559 |
| Flute Length (Decimal Inch) | 0.6693 |
| Flute Length (mm) | 17.00 |
| Shank Diameter (Inch) | 1/4 |
| Shank Diameter (Decimal Inch) | 0.2500 |
| Shank Diameter (mm) | 6.35 |
| Flute Type | Spiral |
| Number of Flutes | 2 |
| Shank Type | Straight-Cylindrical |
| Tool Performance | General Purpose |
| Tool Application | Spotting |
| Cutting Direction | Right Hand |
