Indexable Turning Toolholder: XWXPR3232P09, 100.000 deg Lead Angle, Clamp & Screw
Item #: 63761233
Brand: Tungaloy
Model #: 6852755
Product Specifications
| Toolholder Style | XWXP |
| Hand of Holder | Right Hand |
| Lead Angle | 100.000 |
| Insert Compatibility | WP..0907 |
| Insert Holding Method | Screw; Clamp |
| Shank Width (mm) | 32.00 |
| Shank Height (mm) | 32.00 |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Compatible Insert Size Code | WP..0907 |
| Multi-use Tool | Yes |
| Series | XWXP |
| Cutting Tool Application | Facing; Turning |
| Head Length (mm) | 35.00 |
| Back of Bar to Cutting Edge (mm) | 40.00 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Decimal Inch) | 0.5910 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.2760 |
| Toolholder Style | XWXP |
| Hand of Holder | Right Hand |
| Lead Angle | 100.000 |
| Insert Compatibility | WP..0907 |
| Insert Holding Method | Screw; Clamp |
| Shank Width (mm) | 32.00 |
| Shank Height (mm) | 32.00 |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Compatible Insert Size Code | WP..0907 |
| Multi-use Tool | Yes |
| Series | XWXP |
| Cutting Tool Application | Facing; Turning |
| Head Length (mm) | 35.00 |
| Back of Bar to Cutting Edge (mm) | 40.00 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Decimal Inch) | 0.5910 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.2760 |
| MSC Part # | 63761233 |
| Mfr Part # | 6852755 |
| Country of Origin Country of Origin is subject to change | Japan |
