Brand: Widia / Part #: 2748199
Item #: 90228701
Brand: Widia
Model #: 2748199
Product Specifications
| Thread Standard | NPT |
| Material | High Speed Steel |
| Overall Length (Inch) | 2-7/16 |
| Threads per Inch | 18 |
| Thread Size (Inch) | 1/4-18 |
| Application | Metal |
| Material Application | Non-Ferrous Metal |
| Shank Diameter (Decimal Inch) | 0.5625 |
| Square Size (Decimal Inch) | 0.4210 |
| Chamfer | Plug |
| Series | 5320 |
| Thread Length (Decimal Inch) | 1.0625 |
| Coating/Finish | Uncoated |
| Thread Pitch (Decimal Inch) | 0.0556 |
| Square Length (Decimal Inch) | 0.4375 |
| Thread Depth (Decimal Inch) | 1.0625 |
| Number Of Flutes | 4 |
