External Self-Locking Retaining Ring: 0.06" Groove Dia, 1/2" Shaft Dia, 15-7 Grade 632 Stainless Steel
Item #: 14386460
Brand: Rotor Clip
Model #: TY-50SS
Product Specifications
| Ring Type | Self-Locking |
| Shaft Diameter (Inch) | 1/2 |
| Groove Diameter (Decimal Inch) | 0.0600 |
| Material | Stainless Steel |
| Free Diameter (Decimal Inch) | 0.4980 |
| Free Outside Diameter (Decimal Inch) | 0.5020 |
| Military Specification | Does Not Meet Military Specifications |
| Material Grade | 15-7 Grade 632 |
| Standards | ISO 13485.2016 |
| Ring Thickness (Decimal Inch) | 0.0150 |
| Ring Thickness Tolerance (Decimal Inch) | -0.0020 to 0.0020 |
| Thrust Load Capacity | 50 |
| Minimum Shaft Diameter (mm) | 12.70 |
| Minimum Shaft Diameter (Decimal Inch) | 0.4980 |
| Maximum Shaft Diameter (mm) | 12.70 |
| Maximum Shaft Diameter (Decimal Inch) | 0.5020 |
| Outside Diameter Tolerance (Decimal Inch) | -0.0050 to 0.0050 |
| UNSPSC Code | 31163202 |
| Manufacturer's Part Number | TY-50SS |
| System Of Measurement | Inch |
| Finish Coating | Bright/Uncoated |
| Number Of Prongs | 6 |
