Dayton Lamina - 1/2" Hole Diam, 9/32" Rod Diam, 3" Free Length, Blue Die Spring - 5 Lb Max Deflection, 1.12" Max Deflection, Medium Duty, Chromium Vanadium Steel
Item #: 76012277
Brand: Dayton Lamina
Model #: 9-0812-21
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 1/2 |
| Rod Diameter (Inch) | 9/32 |
| Free Length (Inch) | 3 |
| Load Type | Medium-Duty |
| Color | Blue |
| Maximum Deflection Load (Lb.) | 5.00 |
| Maximum Deflection (Decimal Inch) | 1.1200 |
| Travel To Solid Load (Decimal Inch) | 1.5400 |
| Wire Shape | D-Shaped |
| Material | Chromium Vanadium Steel |
