Circuit-Lock NEMA 3/3R Enclosure Switch Disconnect, 2-Pole, 30A
Item #: 06942312
Brand: Hubbell Wiring Device-Kellems
Model #: HBL13R22
Product Specifications
| Enclosure Type | Enclosed |
| Fused | Non-Fused |
| Amperage | 30 mA |
| Voltage | 600V AC |
| Horsepower at 1 Phase | 2 @ 120 VAC |
| Horsepower at 3 Phase | 5 @ 240 VAC/10 @ 480 VAC/15 @ 600 VAC |
| Contact Form | 2PST |
| Number Of Poles | 2 |
| Overall Height (Decimal Inch) | 4.5500 |
| Overall Width (Decimal Inch - 4 Decimals) | 2.99 |
| Overall Depth (Decimal Inch) | 5.42 |
| Number Of Wires | 1 |
| Material | Thermoplastic |
| Standards | CSA-C22.2 No.14 Industrial Control File LR-46186; UL 508, Industrial Control File #E70402 |
| Nema Rating | 3R |
| Number Of Phases | 3 |
| UNSPSC Code | 39122205 |
