Baileigh - Floor & Bench Drill Presses Stand Type: Floor Machine Type: Drill & Tap Press
Item #: 70320700
Brand: Baileigh
Model #: DP-1500G
Exact Tooling IR#: 04
Features and Benefits
Floor drill presses, also known as standing drill presses, offer more power options than bench drill presses. They are most suited for heavy-duty operations.
Drill and tap presses are gear headed machines with forward and reversing spindles specifically for drilling and tapping operations.
Variable speed pulleys are driven by a V-shaped belt system and a variable speed assembly that regulates an infinite speed range change by the turn of a dial.
Three-phase refers to three individual lines (coils) that connect to and run voltage through the motor. Each line alternates in a sequence as they reach their voltage peak. They provide a more stable flow of voltage and more horsepower to the equipment.
Product Specifications
Floor & Bench Drill Presses; Stand Type: Floor ; Machine Type: Drill & Tap Press ; Swing Distance (Inch): 26-1/2 ; Spindle Speed Control: Variable Speed Pulley ; Phase: 3 ; Spindle Taper Size: 4MT
| Stand Type | Floor |
| Machine Type | Drill & Tap Press |
| Swing Distance (Inch) | 26-1/2 |
| Spindle Speed Control | Variable Speed Pulley |
| Phase | 3 |
| Spindle Taper Size | 4MT |
| Spindle Travel Length (Decimal Inch) | 7.4800 |
| Horsepower (HP) | 3.5 |
| Voltage | 220 |
| Minimum Spindle Speed (RPM) | 108 |
| Maximum Spindle Speed (RPM) | 1800 |
| Drilling Capacity in Steel (Inch) | 1-1/2 |
| Tapping Capacity in Steel (Inch) | 1.3000 |
| Tapping Capacity in Steel (Decimal Inch) | 1.3000 |
| Number of Spindle Speeds | 8 |
| Table Length (Decimal Inch) | 20.0000 |
| Table Width/Diameter (Decimal Inch) | 16.0000 |
| Base Length (Decimal Inch) | 19.5000 |
| Base Width (Decimal Inch) | 28.0000 |
| Column Diameter (Decimal Inch) | 5.5000 |
| Overall Length (Decimal Inch) | 37.0000 |
| Overall Depth (Decimal Inch) | 23.0000 |
| Includes | Chuck; Complete Coolant System; Work Light |
