Hydraulic Hose Fittings & Couplings; Type: PD-Series Diagnostic Interchange Female NPT Plug; Fitting Type: Female Plug; Hose Inside Diameter (Decimal Inch): 0.2500; Hose Size: 1/4
Item #: 56591126
Brand: Dixon Valve & Coupling
Model #: PD1F2
Product Specifications
| Type | PD-Series Diagnostic Interchange Female NPT Plug |
| Fitting Type | Female Plug |
| Hose Inside Diameter (Decimal Inch) | 0.2500 |
| Hose Size | 1/4 |
| Material | Steel |
| Thread Type | NPTF |
| Thread Size (Inch) | 1/4-18 |
| Shape | Straight |
| Connection Type | Threaded |
| Maximum Working Pressure (Psi - 3 Decimals) | 6000.000 |
| Overall Length (Decimal Inch) | 1.8800 |
| Epa Watersense Certified | No |
| Series | PD |
| Valve/Non-Valved | Valved |
| Body Diameter (Inch) | 1/8 |
| Hose Diameter (Inch) | 1/4 |
| UNSPSC Code | 40141734 |
| Type | PD-Series Diagnostic Interchange Female NPT Plug |
| Fitting Type | Female Plug |
| Hose Inside Diameter (Decimal Inch) | 0.2500 |
| Hose Size | 1/4 |
| Material | Steel |
| Thread Type | NPTF |
| Thread Size (Inch) | 1/4-18 |
| Shape | Straight |
| Connection Type | Threaded |
| Maximum Working Pressure (Psi - 3 Decimals) | 6000.000 |
| Overall Length (Decimal Inch) | 1.8800 |
| Epa Watersense Certified | No |
| Series | PD |
| Valve/Non-Valved | Valved |
| Body Diameter (Inch) | 1/8 |
| Hose Diameter (Inch) | 1/4 |
| UNSPSC Code | 40141734 |
| MSC Part # | 56591126 |
| Mfr Part # | PD1F2 |
| Country of Origin Country of Origin is subject to change | Taiwan |
